- The top-notch series of processors offered by MediaTek includes- Helio X27(MT6797X) and Helio X30 (MT6799), Helio X25(MT6797T), Helio X20(MT6797), they also have P series processors named Helio P20(MT6757), Helio P25(MT6757T), including recent Helio P60 and the latest Helio P70 and P90. Let’s talk about the basic structure of the manufacturer.
- + MediaTek Helio X20 – Read / Write Flash, Format, IMEI Repair, Read/Reset Pattern Lock, FRP (Google Lock), Other Extra Options.
I was porting a ROM for my device (mtk 6753 to mtk 6753). My base ROM is Lineage OS 14.1 and the ROM i want to port is Resurrection Remix (Android 7.1) I was following the mtk porting guides but i faced a problem. The problem is that the porting guides says to copy all 'system/libs'.
The Mediatek X20 Development Board is a 96Boards compliant community board based on the MediaTek X20 series of SoCs. X20 is a highly integrated application processor that includes Dual-core ARM Cortex-A72 processors operating at up to 2.3GHz, Quad-core ARM Cortex-A53 processors operating at up to 1.95GHz, Quad core ARM Cortex-A53 processors operating at up to 1.4GHz and a Mali T880 GPU operating at up to 800MHz. In addition, an extensive set of interfaces and connectivity peripherals are included to interface to cameras, touch-screen displays and MMC/SD cards. It also fully supports wireless communication, including WLAN, Bluetooth ® wireless technology and GPS.
Buy Now
Additional Information
| Component | Description |
|---|---|
| SoC | Helio X20 |
| CPU | 2x ARM Cortex-A72 @ 2.1GHz ~ 2.3GHz 4x Cortex-A53 @ 1.95GHz 4x Cortex-A53 @ 1.4GHz |
| GPU | ARM Mali-T880 GPU operating at up to 800MHz |
| RAM | DDR: 2GB LPDDR3 |
| PMU | MT6351 |
| Storage | 8GB eMMC5.1 on board storage MicroSD card slot |
| Ethernet Port | USB2.0 expansion |
| Wireless | Wi-Fi 802.11 a/b/g/n + Bluetooth 4.1 |
| USB | 2 x USB2.0 Host 1 x USB 2.0 OTG |
| Display | 1 x HDMI 1.4 (Type A - full) 1 x MIPI-DSI HDMI output up to FHD 1080P |
| Video | 1080p@30 fps HD video encoding, supporting 1080p@30 fps HD camera 1080p@30 fps HD video decoding Supports H.264, SVC, MPEG1/2/4, H.263, VC-1, WMV9, DivX, RV8/9/10, AVS, VP8 |
| Audio | HDMI output |
| Camera | One 4-lane MIPI camera serial interface(CSI), one 2-lane MIPI CSI |
| Expansion Interface | 40 pin low speed expansion connector: +1.8V, +5V, SYS_DCIN, GND, UART, I2C, SPI, PCM, PWM,GPIO x12 60 pin high speed expansion connector: SDIO, MIPI_DSI, MIPI_CSI |
| LED | 1 x WiFi activity LED（Yellow） 1 x BT activity LED (Blue) 4 x User LEDs (Green) |
| Button | Power Button ： Button Power on/off & Reset the system |
| Power Source | 8V~18V@3A, Plug specification is inner diameter 1.7mm and outer diameter 4.8mm |
| OS Support | Android Marshmallow 6.0 |
| Size | 85mm x 54mm |
Mtk Helio X20 Antutu
Please visit the MediaTek X20 Hardware User Manual for more information
